HSO2002GVW is a GPON ONU aimed at the characteristics of broadband network construction for families and SOHO users, and integrated with VOIP, WLAN AP, gigabit network port, gigabit network port and one family gateway device. This machine adopts RALTEK ONU + WIFI G/EPON compatible high-performance chip, the optical network unit follows the international standard of g. 988, as well as the technical requirements of PON equipment of China telecom, it has good interoperability and operability, and can achieve interconnection with OLT equipment of mainstream manufacturers in the industry. The PON port of this machine is compatible with G/EPOM, with 1 GE and 1 FE Ethernet port connected, 2*2 external double antenna (300Mbps), and a long WIFI transmission distance. The machine is also equipped with optical network unit and WIFI working status indication on the front panel, which is characterized by convenience, simplicity and good reliability.
♦ Products comply with IEEE 802.3ah, 802.11b/g/n, g. 988 international standards,
The communication industry standard of the People's Republic of China (YD/T 1475-2006), as well as the technical requirements of PON equipment of China telecom, has good interoperability and operability, and can achieve interconnection with OLT equipment of mainstream manufacturers in the industry, and G/EPON software and hardware are compatible with each other.
♦ 1GE+1FE+VOIP+2*2WIFI external antenna, WIFI transmission distance, convenient configuration, easy to use;
♦ Data support automatic Concorde automatic detection of MDI/MDIX, built-in layer 2 switches, advanced data features such as VLAN marking operations, classification and filtering;
♦ Video supports video content delivered in the form of data (multicast or unicast);
♦ Operation maintenance management: itu-t g.988 (GPON) alarm and performance monitoring as defined by the standard OMCI(embedded operation channel) interface, remote software image download in OMCI, as well as activation and restart, firmware double-zone backup, with software integrity check and automatic fallback function.
| Items | Units | Specifications | |
| optical properties | Working wavelength | nm | TX1310，RX1490 |
| Optical transmitter power | dBm | 1月4日 | |
| Optical reception sensitivity | dBm | ≥-27 | |
| Optical reflection loss | dB | ≥45 | |
| Optical adapter | / | SC/UPC | |
| Others | WIFI | / | 2*2 2.4GHz 300Mbps(External double antenna） |
| VOIP | / | 1个Pots(RJ11 port) | |
| User Ethernet Ports | / | 1GE（10/100/1000Mbps）+1FE（10/100Mbps），RJ45 port | |
| Type | / | HGU | |
| Power Supply/Consumption | V/A | OutlayAV90～250V→DC12V/1A | |
| Working/Storage Temperature | ℃ | -5～40/-20～75（relative humidity5-85%） | |
| Size | mm | 181*118*33 | |
Product Name | Model | Functional Description |
G/EPON ONU | HSO2002GVW | G/EPON ONU, PON port access, 1GE+1FE Network interface，1 POTS，2*2 2.4G WIFI（External antenna antenna 300Mbps)，operating wavelength1310/1490nm，sending power1～4dBm，received power -27dBm; external 90~255V-12V 1A Power Adapter |
